Features

• Length: 7.0
• Width: 4.5
• Height: 7.0
• Thickness: 7.0
• Diameter: 18.0
• Weight: 0.124
• Power: 21.0
• Voltage: 690.0
• Amperage: 18.0
• Material: Plastic
• IP rating: 20
• Location: Door
• Power source: Cabled
• Number of pieces: 21.0

Schneider Electric: Thermal Overload Relay, TeSys Lrd, 12-18A

Overload relays designed to protect ac circuits against overloads, phase failure, long starting times and prolonged stalling of the motor.

Features and Benefits:
-Adjustable relay setting dial and manual/auto reset for easy control and use
-Trip indicator and sealable cover increase versatility
-Direct mounting or independent mounting on DIN rail

Typical Applications:
-Protecting ac circuits

*Images are for illustration purposes only*
MPN: 3389110346831
EAN: 3389110346831

Thermal Overload Relay, TeSys Lrd, 12-18A Attributes:

Contact Points:	2
Current Rating:	18A
MFR Part No.:	LRD21
Maximum Operating Temperature:	55°C
Minimum Operating Temperature:	-20°C
Motor Rating:	12 to 18A
Mounting Type:	Direct
Overall Depth:	66mm
Overall Height:	123mm
Overall Width:	45mm
Voltage Rating:	690V
